Custom Driveway Gates

Custom Gate Packages

Column

Package #1 Flat Top

$4,950.00 installed with Amercian Armor solar gate operator.

$5,350.00 installed with Patriot solar gate operator.

Column

Package #2 Double Flat Top

$4,950.00 installed with American Armor solar gate operator.

$5,350.00 installed with Patriot solar gate operator.

Column

Package #3 Arch Top

$4,950.00 installed with American Armor solar gate operator.

$5,350.00 installed with Patriot solar gate operator.

Column

Package #4 Double Arch Top

$5,350.00 installed with American Armor solar gate operator.

$5,750.00 installed with Patriot 1 solar gate operator.

Column

Package #5 Alamo Roll Top

$5,350.00 installed with American Armor solar gate operator.

$5,750.00 installed with Patriot 1 solar gate operator.

Column

Package #6 Dual Bi-parting Flat Top Gate

$7,800.00 installed. Includes Patriot 2 solar dual gate operator.

Column

Package #7 Dual Bi-parting Arch Top Gate

$8,600.00 installed. Includes Patriot 2 solar dual gate operator.

We have combined our most popular iron gate styles with reliable, user friendly gate operator equipment. We offer complete installed gate packages within our listed service area.

We provide free onsite estimates, a written quote, and a gate design drawing for your approval.

Please see our Gallery for more custom gate ideas.

Column

Gate Specs:

Single swing in any length up to 14'.

Dual swing in any length up to 20'.
Any frame height up to 6'.

Custom sizing to fit existing openings.
Baked on powder coated paint finish.
Heavy duty adjustable welded block hinges with grease fitting and ball bearing.
Includes 4" steel square tube gate posts.
Includes post holes, concrete, onsite welding.
Includes optional- ranch brand, logo, address, ranch name, etc.
We provide a gate design drawing for your approval before your custom gate is built.

Column

American Armor gate operator specs:

Made in the U.S.A.
3 year warranty.
Solar or A/C compatible.
Auto close timer.
Rated for gates up to 16' in length and 500 lbs.
Our American Armor gate operators include a 12 Volt, 55 amp hr., sealed maintenance free AGM battery, 10 Watt solar panel (for solar option), battery charger (for A/C option), Multicode radio receiver, and two Multicode push button remote transmitters.

Patriot gate operator specs:

Made in the U.S.A.
5 year control board warranty. 3 year warranty on all other parts.
Solar or A/C compatible.
Soft Stop/Start.
Auto close timer.
Hold open feature for parties, deliveries, projects, etc.
Rated for gates up to 16' in length and 650 lbs.
Our Patriot operators include a 12 Volt, 55 amp hr., sealed maintenance free AGM battery, 10 Watt solar panel (for solar option), battery charger (for A/C option), LCR radio receiver, and two LCR push button remote transmitters.
